SPECIFICATION :
Frame
Genius Alloy 6061 custom butted
Hydroformed tubes / tapered Headtube
BB92 / IDS SL DM dropout for 142x12mm
U-Mono Link / rear 180PM
BB height adj.
Travel
700 Series: Front 150mm
Rear 150 - 100 - Lockout / Shock 200X57
900 Series: Front 140mm
Rear 130 - 90 - Lockout / Shock 190X50
Fork
FOX 34 Float Rhythm
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout
Rear Shock
FOX Float Performace
3 modes / Lockout - Trail - Descend
DPS / Reb. Adj.
Remote System
SCOTT TwinLoc Remote Technology
3 modes front and rear
Headset
Syncros Pro Press Fit / Tapered 1.5" - 1 1/8"
OD 50/61mm / ID 44/55mm
Rear Derailleur
Shimano XT RD-M786 SGS
DM / Shadow Plus / 20 Speed
Front Derailleur
Shimano Deore FD-M618-E / DM
Shifters
Shimano Deore SL-M610-I / Rapidfire Plus
2 way release w/gear indicator
Brakes
Shimano M506 Disc
180mm F & R / SM-RT54 CL Rotor
Crankset
Shimano FC-M627-2 / 2-piece Design
36x22 T
BB-Set
Shimano BB-MT500-PA / shell 41x89.5mm
Handlebar
Syncros FL2.0 mini Riser / Alloy 6061D.B.
12mm rise / 9° / 740mm
Handlebar Stem
Syncros TR2.0
6061 / 3D forged / oversize 31.8mm
1 1/8" / 700 Series: +6° / 900 Series: -6°
Seatpost
Syncros Dropper 2.0 / YSP12 ICR / Remote
31.6mm / S size 100mm / M, L & XL 120mm
Seat
Syncros XM2.0 / CROM rails
Hub (Front)
Shimano HB-M618-B CL / 15x110mm
Hub (Rear)
Shimano FH-M618 CL / 12x142mm
RWS axle
Chain
KMC X10
Cassette
Shimano CS-HG50-10 / 11-36 T
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-25 / 32H / Tubeless ready
Tires
Schwalbe Nobby Nic Performance / 2.35
67EPI Kevlar Bead
Dual compound
Weights
13.40kg / 29.54lbs
